Description
- 12” (300 mm) Elevated machine
- Non-stop feeder
- Double sheet detector
- O.S. (operator side) pull guide
- Electrical double sheet detector
- Two (2) cutting chases (quick-lock style)
- One (1) 4mm cutting plate
- Two (2) lower stripping frames with tooling
- Upper blanking frame with pneumatic quick lock device
- Lower blanking support frame
- One (1) full sheet delivery device
- Centerline system
- Touch screen machine interface electronic display 10.4 x 5.7 inches
- Chase changer above the platine section
- Double action stripping station
- Two (2) upper stripping frames with quick locking with tooling
Specifications
| Manufacturer | MK |
| Model | 1060ER/ERS DIE CUTTING MACHINE |
| Year | 2012 |
| Condition | Used |
| Stock Number | 22 |
| Maximum sheet size | 41 3/4” x 30” ( 1060 mm x 760 mm ) |
| Minimum sheet size | 15 3⁄4” x 13 3/4” ( 400 mm x 350 mm) Cutting force : 260 metric tons |
| Maximum production rate | 6,500 sheets per hour |
| Processed material | 90 to 2000 gsm |
| Machine voltage | 600 V / 60 Hz / 30 A ; full load = 380 V / 60 Hz / 46 A |
| Hour Count (Usage) | Machine running hours = 20088 hours |
